RUBBER HOSES





Hydraulic hoses with rubber cover and different types of reinforcement.

  • single/double reinforced with steel braids acc. to EN853 / SAE J517
  • single/double reinforced with compact steel braids acc. EN857 / SAE J517
  • reinforced with four or six steel spirals acc. to EN856 / SAE J517
  • single/double reinforced with textile braids acc. to EN854 / SAE J517

On request steel reinforced hoses can be provided with abrasion resistant covers.

Guidances for hydraulic hoses



E7 - SAE 100R1AT / EN853 1SN

TUBE: oil resistant synthetic rubber
REINFORCEMENT: one high tensile steel wire braid
COVER: abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for medium pressure and hydraulic systems, fuel, mineral oils, glycol, gasolines and lubricants

Product sheet

E7-HT - EN 853 1SN - 135°C

TUBE: oil resistant synthetic rubber
REINFORCEMENT: one high tensile steel wire braid
COVER: heat, abrasion, ozone and weather resistant synthetic rubber
APPLICATION: high temperature, fuel, mineral, synthetic oils, glycols & polyglycols, aqueous oil emulsions (up to 100°C)

Product sheet

J4 - SAE 100 R2AT / EN 853 2SN

TUBE: oil resistant synthetic rubber
REINFORCEMENT: two high tensile steel wire braids
COVER: abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for high pressure hydraulic systems, fuel, mineral oils, glycol, gasolines & lubricants

Product sheet

J4-HT - EN 853 2SN - 135°C

TUBE: oil resistant synthetic rubber
REINFORCEMENT: two high tensile steel wire braids
COVER: heat, abrasion, ozone and weather resistant synthetic rubber
APPLICATION: high temperature, fuel, mineral, synthetic oils, glycols & polyglycols, aqueous oil emulsions (up to 100°C)

Product sheet

DE7 - EN 857 1SC

TUBE: oil resistant synthetic rubber
REINFORCEMENT: one high tensile steel wire braid
COVER: abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for medium pressure and hydraulic systems, fuel, mineral oils, glycol, gasolines and lubricants

Product sheet

HDE7 - exceeds EN 857 1SC

TUBE: oil resistant synthetic rubber
REINFORCEMENT: one high tensile steel wire braid
COVER: abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for medium pressure hydraulic systems, fuel, mineral oils, glycol, gasoline & lubricants

Product sheet

DJ4 - SAE 100 R16 / EN 857 2SC

TUBE: oil resistant synthetic rubber
REINFORCEMENT: two high tensile steel wire braids
COVER: abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for high pressure hydraulic systems, fuel, mineral oils, glycol, gasolines & lubricants

Product sheet

HDJ4 - exceeds SAE 100 R16 / EN 857 2SC

TUBE: oil resistant synthetic rubber
REINFORCEMENT: two high tensile steel wire braids
COVER:  abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for high pressure hydraulic systems, fuel, mineral oils, glycol, gasolines & lubricants

Product sheet

HDJ4-BRS-HA - SAE 100 R16 / EN 857 2SC - BRIDGESTONE

TUBE: oil resistant synthetic rubber
REINFORCEMENT: two high tensile steel wire braids
COVER:  abrasion, ozone and weather resistant synthetic rubber, MSHA flame retardant
APPLICATION: for high pressure hydraulic systems, fuel, mineral oils, glycol, gasolines & lubricants

Product sheet

R17 - SAE 100 R17

TUBE: oil resistant synthetic rubber
REINFORCEMENT: one or two high tensile steel wire braids
COVER:  abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for medium pressure hydraulic systems, fuel, mineral oils, glycol, gasoline & lubricants

Product sheet

R19 - SAE 100 R19

TUBE: oil resistant synthetic rubber
REINFORCEMENT: two high tensile steel wire braids
COVER:  abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for high pressure hydraulic systems, fuel, mineral oils, glycol, gasoline & lubricants

Product sheet

PILOT - pilot lines

TUBE: oil resistant synthetic rubber
REINFORCEMENT: one high tensile steel wire braid
COVER:  abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for medium pressure hydraulic systems, fuel, mineral oils, glycol, gasoline & lubricants

Product sheet

DG3 - 3 layers of steel braid

TUBE: oil resistant synthetic rubber
REINFORCEMENT: three high tensile steel wire braids
COVER:  abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for high pressure hydraulic systems, fuel, mineral oils, glycol

Product sheet

L2 - EN 856 4SP

TUBE: oil resistant synthetic rubber
REINFORCEMENT: four high tensile steel spirals
COVER:  abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for high pressure hydraulic systems, fuel, mineral oils, glycol

Product sheet

S4 - EN 856 4SH

TUBE: oil resistant synthetic rubber
REINFORCEMENT: four high tensile steel spirals
COVER: abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for very high pressure hydraulic systems, fuel, mineral oils, glycol

Product sheet

R15 - SAE 100 R15

TUBE: oil resistant synthetic rubber
REINFORCEMENT: four or six high tensile steel spirals
COVER:  abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for very high pressure hydraulic systems, fuel, mineral oils, glycol

Product sheet

R15-BRS-HA - SAE 100 R15 - BRIDGESTONE

TUBE: oil resistant synthetic rubber
REINFORCEMENT: four high tensile steel spirals
COVER:  abrasion, ozone and weather resistant synthetic rubber, MSHA flame retardant
APPLICATION: for very high pressure hydraulic systems, fuel, mineral oils, glycol

Product sheet

DEE7 - REINIGING - 250 BAR - 155°C

TUBE: synthetic rubber resistant against cold and hot water with usual cleaning agents
REINFORCEMENT: one braid of high tensile steel wire
COVER: abrasion, ozone and weather resistant and resistant to animal grease
APPLICATION: for high pressure cleaning applications with hot water

Product sheet

DJE4 - REINIGING - 400 BAR - 155°C

TUBE: synthetic rubber resistant against cold and hot water with usual cleaning agents
REINFORCEMENT: two braids of high tensile steel wire
COVER:  abrasion, ozone and weather resistant and resistant to animal grease
APPLICATION: for high pressure cleaning applications with hot water

Product sheet

A1 - SAE 100 R6 / EN 854 R6

TUBE: oil resistant synthetic rubber
REINFORCEMENT: one high tensile synthetic textile braid
COVER:  abrasion, ozone and weather resistant synthetic rubber
APPLICATION: low pressure hydraulic systems, fuel, mineral oils, glycol, gasoline & lubricants

Product sheet

T1 - EN 854 1TE

TUBE: oil resistant synthetic rubber
REINFORCEMENT: one high tensile synthetic textile braid
COVER:  oil, abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for hydraulic control lines, discharge under low pressure of hydraulic fluids, fuel, water, oil, air & water

Product sheet

T2 - EN 854 2TE

TUBE: oil resistant synthetic rubber
REINFORCEMENT: one high tensile synthetic textile braid
COVER:  oil, abrasion, ozone and weather resistant synthetic rubber
APPLICATION for hydraulic control lines, discharge under low pressure of hydraulic fluids, fuel, water, oil, air & water

Product sheet

T3 - EN 854 3TE

TUBE: oil resistant synthetic rubber
REINFORCEMENT: two high tensile synthetic textile braids
COVER:  oil, abrasion, ozone and weather resistant synthetic rubber
APPLICATION: for hydraulic control liness, discharge under medium pressure of hydraulic fluids, fuel, water, air & water

Product sheet

U2 - SAE 100 R4

TUBE: oil resistant synthetic rubber
REINFORCEMENT: textile layers, zinc plated steel helix
COVER:  abrasion, ozone and weather resistant synthetic rubber
APPLICATION: oil suction lines and low pressure return lines of hydraulic systems, fuel, gasoline, air & water

Product sheet

U2-HT - SAE 100 R4 - 135°C

TUBE: high temperature hydraulic oil resistant special synthetic rubber
REINFORCEMENT: textile layers, zinc plated steel helix
COVER:  oil, abrasion, ozone and weather resistant synthetic rubber
APPLICATION: oil suction lines and low pressure return lines of hydraulic systems, fuel, gasoline, air & water

Product sheet



Product type:

Hydraulic hoses with rubber cover and different types of reinforcement.

Hoses with thermoplastic cover and different types of reinforcement.

Hoses with stainless steel braid and teflon (PTFE) internal cover.

Accesories for hoses such as sleeves, handles, security...
